Name: Address Points

Display Field: STREET_NAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>The Virginia Geographic Information Network (VGIN) is coordinating the development and maintenance of a statewide Address Point data layer in conjunction with local governments across the Commonwealth in order to create a seamless feature class with address numbers and road names to complement the Virginia Base Mapping Program's (VBMP) Road Centerline (RCL) product by providing even more accurate geocoding results. Address Points can be used as a quality control resource for localities and VGIN for checking RCL address range and street name accuracy, which directly assists dispatch mapping systems. The Address Point data leverages the Commonwealth's investment in VBMP digital orthophotography as well as focusing its efforts to create a single statewide address point layer to be used in the VGIN Geocoding Web Service (GWS). Address Points are data developed and produced by Virginia's Local Governments and sent to VGIN along with Road centerline updates. A series of checks are run on the locality data and the schema is pared where necessary. An ETL process is run to match the VA Address Point model.</SPAN></P></DIV></DIV></DIV>

Service Item Id: 08368f90d6b648f0b9e6d1671300dbb6

Copyright Text: Virginia Geographic Information Network (VGIN), Virginia local government GIS

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 9029

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -369704.88359999657
YMin: 60013.231200002134
XMax: 366476.39360000193
YMax: 384847.4707000032
Spatial Reference: PROJCS["VA_Lambert_Conformal_Conic",GEOGCS["GCS_North_American_1983",DATUM["D_North_American_1983",SPHEROID["GRS_1980",6378137.0,298.257222101]],PRIMEM["Greenwich",0.0],UNIT["Degree",0.0174532925199433]],PROJECTION["Lambert_Conformal_Conic"],PARAMETER["False_Easting",0.0],PARAMETER["False_Northing",0.0],PARAMETER["Central_Meridian",-79.5],PARAMETER["Standard_Parallel_1",37.0],PARAMETER["Standard_Parallel_2",39.5],PARAMETER["Latitude_Of_Origin",36.0],UNIT["Meter",1.0]]

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [255, 197, 0, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[230, 0, 0, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SITEADDID ( type: esriFieldTypeDouble, alias: Site Address ID )
• ADDPTKEY ( type: esriFieldTypeString, alias: Address Point ID, length: 20 )
• PREADDRNUM ( type: esriFieldTypeString, alias: Address Number Prefix, length: 5 )
• ADDRNUM ( type: esriFieldTypeString, alias: Address Number, length: 20 )
• ADDRNUMSUF ( type: esriFieldTypeString, alias: Address Number Suffix, length: 11 )
• UNITTYPE ( type: esriFieldTypeString, alias: Address Unit Type, length: 10 )
• UNITID ( type: esriFieldTypeString, alias: Address Unit Number, length: 10 )
• STREET_PREMOD ( type: esriFieldTypeString, alias: Street Prefix Modifier, length: 2 )
• STREET_PREFIX ( type: esriFieldTypeString, alias: Street Prefix, length: 2 )
• STREET_PRE_TYPE ( type: esriFieldTypeString, alias: Street Pre Type, length: 3 )
• STREET_NAME ( type: esriFieldTypeString, alias: Street Name, length: 60 )
• STREET_TYPE ( type: esriFieldTypeString, alias: Street Type, length: 4 )
• STREET_SUFFIX ( type: esriFieldTypeString, alias: Street Suffix, length: 2 )
• FULLNAME ( type: esriFieldTypeString, alias: Full Street Name, length: 125 )
• FULLADDR ( type: esriFieldTypeString, alias: Full Address, length: 250 )
• PLACENAME ( type: esriFieldTypeString, alias: Place Name, length: 250 )
• FIPS ( type: esriFieldTypeString, alias: Jurisdiction FIPS Code, length: 7 )
• MUNICIPALITY ( type: esriFieldTypeString, alias: Jurisdiction Name, length: 100 )
• ESN ( type: esriFieldTypeString, alias: Emergency Service Number, length: 5 )
• PSAP ( type: esriFieldTypeString, alias: Public Safety Answering Point, length: 4 )
• MSAG_COMMUNITY ( type: esriFieldTypeString, alias: MSAG Community, length: 50 )
• USNGCOORD ( type: esriFieldTypeString, alias: USNG Coordinate, length: 50 )
• LAT ( type: esriFieldTypeDouble, alias: Latitude )
• LONG ( type: esriFieldTypeDouble, alias: Longitude )
• ADDRCLASS ( type: esriFieldTypeInteger, alias: Description )
• POINTTYPE ( type: esriFieldTypeString, alias: Location, length: 30 )
• CAPTUREMETH ( type: esriFieldTypeString, alias: Capture Method, length: 30 )
• STATUS ( type: esriFieldTypeString, alias: Status, length: 30 )
• LASTUPDATE ( type: esriFieldTypeDate, alias: Last Update Date, length: 8 )
• PO_NAME ( type: esriFieldTypeString, alias: Post Office Name, length: 50 )
• STATE ( type: esriFieldTypeString, alias: State Abbreviation, length: 2 )
• ZIP_5 ( type: esriFieldTypeInteger, alias: Zip Code )
